GivEnergy API and GivTCP: Local Control for Your Battery

GivEnergy's open approach to APIs sets it apart from competitors. With GivTCP, you can control your battery locally — no cloud dependency, faster response times, and full integration with Home Assistant for sophisticated automation.

Cloud vs Local Control

GivEnergy Cloud (Default)

When you install a GivEnergy system, it connects to GivEnergy's cloud servers via WiFi. The GivEnergy app and portal show your data via this cloud connection. It works well, but:

• Data updates every 5–60 seconds (varies)
• Control commands go via the internet — slower and dependent on cloud availability
• If GivEnergy's servers go down, you lose monitoring and control
• API rate limits apply

GivTCP (Local)

GivTCP connects directly to your inverter over your home network. It reads data and sends commands locally:

• Data updates in real time (sub-second)
• Control commands are instant — no internet dependency
• Works even if your internet or GivEnergy's cloud is down
• No API rate limits
• Full control of all inverter settings

For Home Assistant and Predbat users, local control via GivTCP is strongly recommended.

What GivTCP Can Do

Read Data

• Real-time solar generation (W)
• Battery state of charge (%)
• Battery charge/discharge rate (W)
• Grid import/export (W)
• Household consumption (W)
• Inverter temperature
• Daily/lifetime generation totals
• Individual string voltages and currents

Control the Inverter

• Set battery charge rate
• Set battery discharge rate
• Set charge target (% SOC)
• Set discharge cutoff (% SOC)
• Switch between modes (eco, timed charge, timed export)
• Set charge/discharge time windows
• Enable/disable battery discharge
• Force charge from grid
• Force export to grid

This level of control is what makes GivEnergy the preferred battery for UK solar automation enthusiasts.

Setting Up GivTCP

Prerequisites

• GivEnergy inverter connected to your WiFi network
• Home Assistant running (on Raspberry Pi, mini PC, or server)
• The inverter's local IP address (find it in your router's connected devices list)

Step 1: Find Your Inverter IP

Log into your router and look for a device named "GivEnergy" or similar in the connected devices list. Note the IP address (e.g., 192.168.1.105).

Step 2: Install GivTCP

GivTCP runs as a Home Assistant add-on or Docker container:

Home Assistant Add-on (easiest):

1. Add the GivTCP repository to your HA add-on store
2. Install the GivTCP add-on
3. Configure with your inverter IP address and serial number
4. Start the add-on

Docker Container (for advanced users): Pull the GivTCP image and configure via environment variables. Useful if you're running HA as a container or have a separate server.

Step 3: Configure

Key configuration settings:

• Inverter IP: The local IP address noted above
• Number of inverters: Usually 1 for residential
• Battery count: Number of battery units connected
• MQTT settings: If using MQTT (recommended for HA integration)

Step 4: Verify

Once running, GivTCP creates MQTT entities in Home Assistant:

• sensor.givtcp_XX_pv_power — current solar generation
• sensor.givtcp_XX_battery_soc — battery percentage
• sensor.givtcp_XX_grid_power — grid import (positive) or export (negative)
• sensor.givtcp_XX_load_power — household consumption

Check that these sensors update in real time. If they do, GivTCP is working correctly.

Using GivTCP with Home Assistant

Energy Dashboard

Map GivTCP sensors to HA's Energy Dashboard:

• Solar production: sensor.givtcp_XX_pv_energy_today
• Grid consumption: sensor.givtcp_XX_import_energy_today
• Grid export: sensor.givtcp_XX_export_energy_today
• Battery charge: sensor.givtcp_XX_battery_charge_energy_today
• Battery discharge: sensor.givtcp_XX_battery_discharge_energy_today

Real-Time Power Flow

Use a power flow card (e.g., Tesla Style Solar Card) to visualise real-time energy flows between solar, battery, grid, and home. This is the most satisfying dashboard to watch — seeing solar power your home and charge your battery in real time.

Battery Control Automations

GivTCP provides service calls for battery control:

Force charge: Call givtcp.set_charge_target with the desired SOC percentage

Set charge window: Call givtcp.set_charge_start and givtcp.set_charge_end with times

Disable discharge: Call givtcp.set_discharge_rate with 0

These service calls are what Predbat uses under the hood to optimise your battery schedule.

GivTCP for Predbat

Predbat requires GivTCP (or similar local control) to manage your battery. The connection is:

1. Predbat reads Octopus pricing and Solcast forecasts
2. Predbat calculates the optimal battery schedule
3. Predbat sends commands to GivTCP
4. GivTCP sends commands to the inverter locally
5. The inverter charges/discharges accordingly

This happens every 30 minutes, adjusting as forecasts and actual conditions change.

The GivEnergy Cloud API (Alternative)

If you prefer not to run GivTCP locally, GivEnergy also provides a cloud API:

• Documentation: api.givenergy.cloud
• Access: Register for an API key via the GivEnergy portal
• Features: Read data, control battery, access historical data
• Limitations: Rate-limited, internet-dependent, slightly delayed data

The cloud API works with Home Assistant via the GivEnergy Cloud integration (HACS). It's simpler to set up than GivTCP but less responsive and less reliable for automated battery management.

For Predbat and other real-time automations, GivTCP is strongly recommended over the cloud API.

Troubleshooting Common Issues

"Can't connect to inverter"

• Verify the IP address is correct
• Check the inverter is connected to WiFi (check the inverter display or GivEnergy app)
• Ensure HA and the inverter are on the same network/VLAN
• Try pinging the inverter IP from HA

"Sensors not updating"

• Check MQTT broker is running (Mosquitto add-on in HA)
• Restart GivTCP add-on
• Verify serial number in configuration matches your inverter

"Control commands not working"

• Check GivTCP version compatibility
• Verify the inverter firmware is up to date
• Some commands are only available in certain inverter modes

To get the most from GivTCP, you need a GivEnergy inverter and battery:

GivEnergy All-in-One 5kW Hybrid Inverter

£1,200

rated power kw

5

max pv input kw

7.5

mppt channels

2

battery voltage v

48V

View on Amazon

Affiliate link — we may earn a small commission at no extra cost to you

GivEnergy All-in-One 9.5kWh Battery

£5,500

capacity kwh

9.5

usable capacity kwh

8.6

chemistry

LFP

cycles

6000

View on Amazon

Affiliate link — we may earn a small commission at no extra cost to you

Why This Matters

The ability to locally control your battery is what makes sophisticated automation possible. Without it, you're limited to the manufacturer's app and basic scheduling. With GivTCP + Home Assistant + Predbat, you have a fully automated energy management system that responds to pricing, weather, and your usage patterns in real time.

This is one of the key reasons GivEnergy is the most popular battery choice for UK solar enthusiasts — the open API philosophy enables a level of control that competitors (particularly Tesla) don't match.

For the full Home Assistant setup, see our Home Assistant guide. For Predbat configuration, see our Predbat guide.
