Solar Carports: Panels on Your Parking Space

If your roof isn't suitable for solar — wrong orientation, too much shading, or not enough space — a solar carport puts panels above your driveway or parking area instead. It's also an option if you want solar but prefer to keep your roof untouched.

What Is a Solar Carport?

A solar carport is a freestanding or semi-attached structure that covers a parking space (or spaces) with solar panels on top. It provides both shelter for your car and electricity generation.

The structure is typically steel or aluminium, tilted at an optimal angle for solar generation (20–35°), and high enough to park underneath comfortably (minimum 2.2m clearance).

Costs

Compare this with roof-mounted solar at £6,000–£8,000 for the same 4kW capacity. The carport structure adds roughly £4,000–£7,000 to the cost.

Generation Potential

A solar carport has one significant advantage over many roof systems: you can orient it optimally. While your roof faces whatever direction the house was built, a carport can be positioned for perfect south-facing exposure at the ideal tilt.

Generation figures assume south-facing, optimal tilt, Midlands location.

Planning Permission

This is the major difference from roof-mounted solar. A solar carport is a new structure that almost always requires planning permission.

Key planning considerations:

• Height and size: Must comply with local permitted development limits for outbuildings
• Boundary distance: Structures within 2m of a boundary have height restrictions
• Conservation areas: Additional restrictions apply
• Front of property: Structures visible from the road face stricter scrutiny
• Flood zones: Additional requirements in flood-risk areas

Typical planning application cost: £230 (householder application in England, 2026).

The EV Charging Synergy

Solar carports make particular sense if you have an electric vehicle:

• Direct connection: Wire an EV charger directly to the carport structure, minimising cable runs
• Covered charging: Charge in the dry, regardless of weather
• Solar-to-car: During the day, excess solar generation charges your car directly
• Visual logic: Panels above the car, charger on the post — the setup makes intuitive sense

A 4kW solar carport generates roughly 3,600 kWh/year. If your EV uses 3,500 kWh/year (typical for 10,000 miles), the carport could theoretically offset your entire driving fuel cost — though in practice you'd only directly charge from solar for part of this.

DIY vs Professional Installation

DIY Carport Structure + Professional Electrical

Some homeowners build the carport frame themselves (or use a steel fabricator) and then have a solar installer fit the panels and electrical. This can save £2,000–£4,000 on the frame compared to a professional install solar carport package.

professional install Solar Carport

Several UK companies offer complete solar carport packages — structure, panels, inverter, and installation. This is more expensive but gives a single point of responsibility for the whole project.

Standard Carport + Retrofit Panels

Buy an off-the-shelf metal carport (£1,500–£3,000) and add solar panels on top. The carport must be engineered to handle the additional weight (panels add roughly 12–15 kg/m²) and wind loading. Not all carports are suitable — check before buying.

Structural Requirements

A solar carport needs to withstand:

• Panel weight: 12–15 kg/m² (roughly 200–300 kg total for a double carport)
• Wind uplift: Panels act as a sail; the structure must resist uplift forces
• Snow load: UK snow loading varies by region but typically 0.5–1.0 kN/m²
• Foundation loads: Posts need adequate footings — typically 600mm × 600mm × 600mm concrete pads

Steel or aluminium frames from specialist manufacturers are designed for these loads. DIY structures must be engineered properly — this isn't a shed build.

EcoFlow Delta Pro 3.6kWh Portable Power Station

£1,500

capacity kwh

3.6

usable capacity kwh

3.4

chemistry

LFP

cycles

3500

View on EcoFlow UK

Affiliate link — we may earn a small commission at no extra cost to you

Payback Analysis

For a double solar carport (5kW system):

If you also offset EV charging costs (instead of paying 26p/kWh for grid electricity at home or 60–80p/kWh at public chargers), the financial case improves significantly.

Compare with roof-mounted solar:

• Roof system cost for 5kW: £8,000
• Payback: ~7 years
• Carport premium: ~£4,000 (for the structure)

The carport structure adds roughly 3 years to the payback. Whether that's worth it depends on whether your roof is an option.

ECO-WORTHY 5.12kWh LiFePO4 Battery Module

£700

capacity kwh

5.12

usable capacity kwh

4.9

chemistry

LFP

cycles

4000

View on Amazon

Affiliate link — we may earn a small commission at no extra cost to you

When a Solar Carport Makes Sense

• Your roof isn't suitable (north-facing, heavily shaded, structurally weak)
• You want to keep your roof clear (aesthetic preference, future roof work planned)
• You have an EV and want a combined solar/charging solution
• You need covered parking anyway and want to combine benefits
• You have space on your property for a new structure

When It Doesn't Make Sense

• Your roof is suitable for panels (much cheaper per kW)
• Planning permission is unlikely (conservation area, visible location, neighbour issues)
• Budget is tight (the structure cost is significant)
• You don't have enough driveway or parking space

For most UK homes with a suitable roof, roof-mounted panels are the more cost-effective choice. Solar carports fill a genuine gap for homes where roof installation isn't practical.
